5.5’ x 5.5’

MAX FLIGHT   25 Feet

SETUP TIME    30 Min

INTERNAL REFLECTOR

Yes/No

SKIRTING

Drapping / 4- pc. (4 sides, 4 ends skirts)

POWER CONFIGURATION

HMI

  • 2 x 200w HMI (400w total)

  • 2 x 575w HMI (115,0w total)

TUNGSTEN

  • 120v - 4 x 650w (2,600w total)

  • 240v - 4 x 1000w (4,000w total)

HYBRID

  • 2 x 200w HMI + 2 x 650w Tungsten (1700w total)

  • 1 x 575w HMI + 1 x 2kw Tungsten (2,575w total)

7.5' X 7.5'





MAX FLIGHT   35 Feet

SETUP TIME    45 Min

INTERNAL REFLECTOR

Yes/No

SKIRTING

Drapping / 8- pc. (4 sides, 4 ends skirts)

POWER CONFIGURATION

HMI

  • 2 x 1,200w HMI (2,400w total)

  • 4 x 575w HMI (2,300w total)

TUNGSTEN

  • 120v - 4 x 650w (2,600w total)

  • 240v - 4 x 1000w (4,000w total)

HYBRID

Any combination up to 4 listed below.    Total output not to exceed 7,400w      (Please double HMI wattage when calculating maximum output)

  • HMI 575w (1,150w)

  • HMI 1200w (2,400w)

  • HMI 2500w (5,000w)

  • Tungsten 2000w

  • Tungsten 3000w

8.5' X 10'





MAX FLIGHT   60 Feet

SETUP TIME    60 Min

INTERNAL REFLECTOR

No

 SKIRTING

8- pc. (4 sides, 4 ends skirts)

POWER CONFIGURATION

HMI

  • 2 x 1,200w HMI (2,400w total)

  • 4 x 575w HMI (2,300w total)

TUNGSTEN

  • 120v - 4 x 650w (2,600w total)

  • 240v - 4 x 1000w (4,000w total)

  • 240v - 2 x 2,500w (5,000w total)

HYBRID

Any combination up to 4 listed below     Total output not to exceed 12,150w    (Please double HMI wattage when calculating maximum output)

  • HMI 575w (1150w)

  • HMI 1200w (2,400w)

  • HMI 2500w (5,000w)

  • HMI 4000w (8,000w)

  • Tungsten 2000w

  • Tungsten 2500w

10.5' X 13'





MAX FLIGHT   100 Feet

SETUP TIME   90 Min

INTERNAL REFLECTOR

No

 SKIRTING

 8- pc. (4 sides, 4 ends skirts)

POWER CONFIGURATION

HMI

  • 4 x 575w HMI (2,300w total)

  • 4 x 1,200w HMI (2,400w total)

  • 4 x 4000w HMI (16,000w total)

TUNGSTEN

  • 120v - 16 x 650w (10,400w total)

  • 240v - 16 x 1000w (16,000w total)

  • 240v - 4 x 5000w (20,000w total)

HYBRID

Any combination of 4 listed below.         Total output not to exceed 20,000w   (Please double HMI wattage when calculating maximum output)

  • HMI 575w (1150w)

  • HMI 1200w

  • HMI 2500w

  • HMI 4000w

  • Tungsten 3000w

  • Tungsten 5000w

18' X 19'





MAX FLIGHT   150 Feet

SETUP TIME   2.5 hrs

INTERNAL REFLECTOR

No

SKIRTING

8- pc. (4 sides, 4 ends skirts)

POWER CONFIGURATION

HMI

  • 8 x 575w HMI (5,200w total)

  • 8 x 1,200w HMI (9,6000w total)

  • 8 x 2500w HMI (20,000w total)

  • 8 x 4000w HMI (32,000w total)

TUNGSTEN

  • 120v - 36 x 650w (36,000w total)

  • 240v - 36 x 1000w (36,000w total)

  • 240v - 8 x 5000w (40,000w total)

 HYBRID

Any combination of 8 listed below.         Total output not to exceed 40,000w

  • HMI 575w

  • HMI 200w

  • HMI 2500w

  • HMI 4000w

  • Tungsten 3000w

  • Tungsten 5000w
