5.5’ x 12’

MAX FLIGHT   35 Feet

SETUP TIME   45 Min

INTERNAL REFLECTOR

Yes

POWER CONFIGURATION

LED

  • 800w Bi-color(2700k-6500k)

  • 800w Warm white 2700k

  • 800w Cool white 6500k

 HMI

  • 4 x 200w HMI (800w)

  • 4 x 575w HMI (2,300w)

TUNGSTEN

  • 120v - 8 x 300w (2,400w)

  • 120v 4 x 1,000w (4,000w)

  • 240v - 8 x 650w (5,200w )

HYBRID

  • 2 x 575w HMI + 2 x 1k Tungsten

    (3150w total)



7' X 14' - 7.5’x 16’





MAX FLIGHT   50 Feet

SETUP TIME   70 Min

INTERNAL REFLECTOR

Yes

POWER CONFIGURATION

LED

  • 1600w Bi-color(2700k-6500k)

  • 1600w Warm white 2700k

  • 1600w Cool white 6500k

 HMI

  • 4 x 575w HMI (2,300w )

  • 4 x 1,200w HMI (4.800w )

TUNGSTEN

  • 120v - 8 x 650w (5,200w )

  • 120v - 4 x 1,000w (4,000w)

  • 240v - 8 x 1000w (8,000w )

HYBRID

  • 2 x 575w HMI + 2 x 1k Tungsten

    (3150w total)

  • 2 x 1.2k HMI + 2 x 2.5k Tungsten (7,400w total)

8.5' X 20'





MAX FLIGHT   75 Feet

SETUP TIME   100 Min

INTERNAL REFLECTOR

Yes

POWER CONFIGURATION

LED

  • 2400w Bi-color(2700k-6500k)

  • 2400w Warm white 2700k

  • 2400w Cool white 6500k

HMI

  • 8 x 575w HMI (4,600w)

  • 8 x 1,200w HMI (9.600w)

  • 4 x 4000w HMI (16,000w)

TUNGSTEN

  • 120v - 8x 1000w (8,000w)

  • 240v - 8 x 2,500w (20,000w)

  • 240v - 4 x 5,000w (20,000w)

HYBRID

  • 4 x 575w HMI + 4 x 1k Tungsten (6300w total)

  • 4 x 1.2k HMI + 4 x 2.5k Tungsten (14,800w total)

9’ x 26’

MAX FLIGHT   100 Feet

SETUP TIME   2 hrs

INTERNAL REFLECTOR

Yes

POWER CONFIGURATION

LED

  • 3200w Bi-color(2700k-6500k)

  • 3200w Warm white 2700k

  • 3200w Cool white 6500k

HMI

  • 8 x 575w HMI (4,600w)

  • 8 x 1,200w HMI (9.600w)

  • 4 x 4000w HMI (16,000w)

TUNGSTEN

  • 120v - 8 x 1000w (8,000w)

  • 240v 8 x 2000w (16,000w)

  • 240v - 4 x 5000w (20,000w)

HYBRID

HYBRID

  • 4 x 575w HMI + 4 x 1k Tungsten

    (6300w total)

  • 4 x 1.2k HMI + 4 x 2.5k Tungsten (14,800w total)
